Linear Solenoids︱Tubular Solenoids∣Push type Solenoids ︱Enclosed Frame Linear Solenoids∣Heavy Linear solenoids∣----DSO60120 (IR-CUT︱Solenoid Valve︱Electromagnets︱Solenoid Pump)
1. Basic size: ￠60mm, L120mm
2. Feature:
1) Linear Solenoids
2) Versatile enclosed construction
3) Operation: Push or Pull
4) Heavy type Solenoids
5) Housing: Nickel palted or Chrome plated
Basic Parameters of the Linear Solenoids | No. | Name | Result |
| 1 | Operating Voltage | DC24~220V |
| 2 | Dielectric Strength | AC1000V (50/60HZ) 1min |
| 3 | Working Temp. | -10℃~180℃ |
| 4 | Temp. Rise | DC36V, below 70℃ |
| 5 | Skroke | 0~50mm |
| 6 | Holding Force | 0~150N |
3. Life expectancy: 1.8 million times (Energized: 2s, De-energized: 2s)
4. Advantage:
1) Strong force
2) Long stroke
3) With flexible motion, rapid response
4) Allow underwater operation
5. Application:
It is mainly used in heavy industrial equipment and so on.
Technical considerations for selecting the enclosed frame Linear Solenoids:
1. Space Envelope
Specify maximum envelope available. Remember the larger the Solenoid the lower the current and operating costs
2. Force Required of the Linear Solenoids
Specify initial requirements
3. Stroke
Stroke is expressed in movement in mm for Linear Solenoids. Specify Push or Pull operation and movement required for Linear Solenoids
4. Duty Cycle
Relative Duty Cycle% = (On Time / (On+ Off Time) x 100%
5. Power Source of the Linear Solenoids
Specify working voltage tolerances and any current limitations
6. Ambient Temperature
Specify working ambient temperature
Instructions:
The Solenoid & Electromagnet is a non-standard component, 100% ODM or OEM is welcome too, just feel free to contact us.
The more you tell us, the best we can do.
|
|
